Coagulator

Power supply of the device: 220 V, 50 Hz
Frequency of the output high-frequency voltage: 880 kHz
OUTPUTS:
monopolar: 1 pc
bipolar: 1 pc
Output power at monopolar output: max 200 +/- 20 W; min 5 W
Output power at bipolar output: max 200 +/- 10 W; min 5 W
Number of power control steps: 10
Switching on high frequency voltage: foot pedal
Power output: 200 W
Time of readiness of the device for work after its connection to the network: 5 seconds
Continuous operation with maximum power output to the load: 300 Ohm
Repeatedly – short-term operation on the load: <300 Ohm
Short-term operation in short circuit mode: 10 sec
Overall dimensions of the electronic unit: 250x190x100 mm
Weight of the electronic unit: 5 kg
APPOINTMENT:
1. The device is designed for coagulation and cutting of soft tissues and blood vessels with high
frequency (HF) current in veterinary medicine, surgery, gynecology, dentistry, cosmetology.
2. The device is intended for use in the premises of veterinary clinics, hospitals,
hospitals.
SCOPE OF DELIVERY:
1. Electronic unit
2. Foot pedal with cable
3. Monopolar tool holder with
cable (length 2.5 m)
4. Electrode-knife straight
5. Surgical electrode set (3
electrodes)
6. Bipolar tweezers
7. Tweezers cable (length 2.5 m)
8. Passive electrode with 2.5 m cable
9. Power supply cable (length
1,8 м)
10. Passport
11. Spare parts kit (fuses – 4 pcs.)
